Abstract
Hybrid bonding is essential for advanced semiconductor packaging, but voids formed during the process can compromise reliability and performance. Traditional non-destructive inspection methods struggle to detect sub-micron voids beneath silicon or metal layers. This work introduces Picosecond Laser Acoustics (PLA), a technique using femtosecond laser pulses to generate and detect acoustic echoes from buried interfaces. Operating in an ASOPS configuration, PLA enables high-resolution imaging of voids as small as 1 µm. Principal Component Analysis (PCA) is used to visualize defects from acoustic and thermal signals. PLA is non-destructive, coupling-free, and ideal for hybrid bonding process control.
Event Details
| Date | Feb 24, 2026 |
|---|---|
| Time | 3:40 pm - 4:00 pm PST |
| Location | San Jose, CA |
| Event | SPIE Advanced Lithography + Patterning |
| Room | 210A, Convention Center |
| Presenters |
